The Amazing New SwellPro Fisherman MAX Heavy Lift FD2 Fishing Drone Review

Last updated on June 18th, 2024 at 11:02 pm

It’s Finally here, The new SwellPro Fisherman Max Heavy Lift FD2 Fishing drone will begin shipping May 1st 2023! SwellPro’s newest fishing drone was, for a brief time, the most powerful, waterproof, fishing drone in the world. Complete with massive 16-inch propellers and powerful 400kv brushless motors, The Fisherman MAX produces up to 33 lbs thrust. Enough To lift 7.7 pounds. If you fish big baits for big fish, and were looking for a drone to fly your baits out, then the SwellPro Fisherman MAX is just what you’ve been looking for.

Quick Look:

The most powerful waterproof drone in the world. Swellpro Fisherman MAX FIRST BEGAN SHIPPING IN MAY 2023. With massive 16-inch diameter propellers, the Fisherman MAX has a 7.7 lb (3.5kg) carrying capacity. Enough to handle big shark baits and gear. It comes with a weather-resistant, case, battery charger, 4K camera, dual bait releases, and remote controller with a built-in 5-inch screen. So, put your smartphone away. Operating range of 1 mile and GPS programmable flights to accurately drop baits “hands-free”. And, it can operate in winds up to 40 mph. It truly is an awesome piece of equipment and I HIGHLY RECOMMEND IT if you fish big baits and need the extra payload capacity.

SwellPro has been making waterproof fishing drones since 2014 and is the established leader in the fishing drone industry. From their Spry, to their Splash Drones to the Fisherman FD1 and now the all new SwellPro Fisherman Max FD2 they have a drone for any fishing style or budget. So, let’s get on with it and unpack the box on the new SwellPro Max and see just what this new fishing drone is all about. And, if it is a good choice for you and your fishing style and situation.

Is Fishing with Drones Legal?


Cartoon character thinking with a red question mark behind him

Is Drone Fishing Legal?

Yes, and No. It depends on where you will be fishing. There are many places in the world where fishing with drones is perfectly legal. However, most parks and many municipalities prohibit drones for any purpose. And, of course, anywhere around the controlled air space of an airport or military base is prohibited as well.

Always take the time to check with the local authorities in your fishing areas. It’s better to know before you go.

Local game and fish departments can help you and local fishing forums can be another good source of information. Please, whatever you do, don’t harass fish and wildlife, or other fisherman and beach goers. Respect the privacy of others and you should be fine. Abuse the privilege, and it could cost us all in the long run.

The SwellPro Drones Story


SwellPro was founded in 2014 by Eric Hu who used his knowledge and background in waterproof cameras to create the first, 100%waterproof, dedicated fishing drones. SwellPro is based in Shenzhen, China, and specializes in the design and manufacture of non-standard drones, payloads and accessories.

They created the first truly waterproof drone. And, Ever since, they have been driven to develop the finest waterproof drones for both amateurs and professionals alike. For everything from filming, fishing, boating and even search and rescue.

Eric Hu - founder of SwellPro
Eric Hu – Founder SwellPro
SwellPro Drones logo
  • Company: SwellPro
  • Address: Room 503, Building 2A, Skyworth Innovation Valley, Bao’an District Shenzhen, China
  • Product: Drones and Drone Accessories
  • Website: swellpro.com
  • Support: support@swellpro.com
  • Founder: Eric Hu
  • Overall Rating: 98 out of 100

SwellPro Fisherman Max Heavy Lift FD2 Fishing Drone


The Fisherman Max FD2 is the newest model in the SwellPro fishing drone line up, and their most powerful one. It’s the fishing drone that anglers all over the world have been waiting for because it has a 7.7 lb payload capacity matching or exceeding any fishing drone currently on the market. This made the Fisherman MAX the most powerful waterproof fishing drone in the world until the release of the Thor 850 Heavy Lift Fishing Drone by IdeaFly.

I fish for big sharks from the beach. It takes big baits to catch big sharks and many of the fishing drones just didn’t have the payload capacity I needed.

The Fisherman MAX solves that problem. Swellpro Fisherman MAX will START SHIPPING IN MAY 2023 with preorders being taken beginning April 23, 2023.

The 16-inch propellers and powerful 400kv brushless motors, provides up to 33 lbs thrust, enough to lift 7.7 pounds and fly in winds up to 40 mph with a max speed of 45mph.

The Fisherman max comes with a high resolution 4K tilt camera and 1 axis gimbal so you can record high-clarity footage and even see smaller details and fish. SwellPro fishing drones are 100 percent Waterproof and the Fisherman MAX is IP67 rated, meaning it is waterproof for up to 30 minutes at the depth of 1 meter. It can land and take off in water and comes with included floats for operating in water for trolling or underwater photography. So, what all comes with your purchase of the Fisherman MAX FD2?

SwellPro Fisherman MAX Fishing Drone Features:

SwellPro Fisherman MAX fd2 fishing drone shown both open and folded for transport
The SwellPro Fisherman MAX folds for easy transport
  • Payload capacity – 7.7 LBS / 3.5 KG Bait Capacity. Target a wider variety of species with a wider option of baits. Take drone fishing to the next level.
  • 4K Camera – Find fishing spots and record your fishing trip of lifetime in 4K. Record high-clarity footage to see even smaller fish and details.
  • Remote Controller with Multi-Color Display – Live video feed for Increasing bait drop accuracy without using a phone. Splash and sand proof Remote Control with built-in 5 inch monitor
  • 1 MILE / 1.5 KM Range – Drop baits far out into the ocean without using a kayak. Keep fishing when it would be too rough to kayak baits out.
  • Foldable Design – Tough, weather and sand resistant, while being super easy to carry to the beach.
  • IP67 Waterproof – 100% waterproof aircraft and splash-proof remote controller. Even if it lands in the water, you’re OK.
  • Level 6 Wind Resistance – Hover and fly stably in strong winds with high-thrust motors. Carry your baits out pasted the breakers when it would be too dangerous by kayak or PWC.
  • Auto-Fish APP(Beta) – Automatically fly to marked fishing spots on the APP to drop baits for “hands free” bait deployment.
  • Safe Return – Automatically drop baits and return to beach in case of emergency, loss of signal or low battery.
Urban Drones banner with logo

What do You Get with the New Swellpro Max FD2


What’s in the box

  • 1- Fisherman Max Drone (Advanced)
  • 1- Remote Controller with 5 inch display screen(Advanced)
  • 1- Intelligent Battery (B-FD2)
  • 1- Power Adapter (C-FD2)
  • 2- Sets of Propellers(P-FD2)
  • 1- 4K Gimbal Camera (GC1-M)
  • 1- Dual Payload Release (DPL)
  • 1- Float set for water operations(FL-FD2)
  • 1- USB-C charging Cable
  • 1-standard charging cable
  • 1- Fisherman MAX FD2 carrying case
SwellPro Fisherman MAX with all components and carrying case

For the tech geeks among us, let’s take a look at the specifications for the various components of the SwellPro Fisherman MAX fishing drone package.

SwellPro Fisherman MAX fishing drone Specifications

  • Waterproof rating: IP67
  • Drone weight (including battery): 8.3 lbs / 3.78 kg
  • Size (w/o propeller): unfold: 20*20*7.5 inch / 522*522*192 mm ; folded: 12*10.5*7.5 inch / 306*266*192 mm
  • Max ascend speed: 7 mph / 3 m/s
  • Max descent speed: 4.5 mph / 2 m/s
  • Max flight speed: ATTI: 45 mph / 20 m/s ; GPS: 22 mph / 10 m/s
  • Max tilt angle: 25°
  • Max flight altitude: 1 mile /1500 m
  • Max flight distance: 1 mile / 1500 m
  • Max image transmission distance: 0.7 mile / 1200 m
  • Max payload capacity: 7.7 lbs / 3.5 kg
  • Flight time: up to 30 mins ( no wind & no load)
  • Max wind speed resistance: 40 mph / 18 m/s / 35 knots
  • Hovering precision: ±1.6 feet / ±0.5 m
  • Satellite positioning system: GPS/Galileo
  • Motor: 4114 ~ 400Kv
  • ESC: 40A
  • Propellers: #1655 carbon fiber
  • Operation frequency: 2.405 ~ 2.475 GHz | 5.725 ~ 5.825 GHz
  • Transmitter power (EIRP): <33 dBm (FCC), <20 dBm (CE) | <33 dBm (FCC), <14 dBm (CE)
  • Working temperature: 14℉ ~ 104℉ / -10℃ ~ 40℃
  • Certifications: CE/FCC/ROHS/RCM

SwellPro Fisherman MAX Battery and Charger Specifications:

Flight Battery

  • Capacity: 4500 mAh
  • Voltage: 22.2V
  • Type: 6S LiPo
  • Size: 8.6*4.7*2.5 inch / 219*119*65 mm
  • Weight: 2.8 lbs / 1255 g
  • Working temperature: 32℉ ~ 104℉ / 0℃ ~ 40℃
  • Charging Time: 80 mins
  • Max Charging current: 8A

Charger

  • Input: 100 – 240V
  • Output: 25.2V
  • Max charging power: 200W
  • Supported battery types and cell: 6S LiPo
  • Size: 5.6*4*2.4 inch / 143*100*60 mm
  • Power cable: 3.9 feet / 1.2 m
  • Charging cable: 1.6 feet / 0.5 m
  • Weight: 1 lbs / 454.6 g
  • Working temperature: 32℉ ~ 140℉ / 0℃ ~ 60℃
  • Available types of power adapter:
  • Type A: USA, Canada, Mexico & Japan
  • Type B: Europe, South America & Asia
  • Type G: United Kingdom, Ireland, Malta & Singapore
  • Type I: Australia & New Zealand

Fisherman MAX Remote Controller Specifications:

Remote Controller

SwellPro Fisherman MAX Remote Controller with built in 5 inch Screen
  • Weight: 1.56 lbs / 709 g
  • Waterproof rating: IP54
  • Size: 11*7.5*3 inch / 276*190*74 mm
  • Operating Frequency: 2.405-2.475 GHz; 5.725 – 5.825 GHz
  • Transmitter Power (EIRP): 2.405-2.475GHz: <26 dBm (FCC), <20 dBm (CE)
  • Latency: 20 ms
  • Battery: 3000mAh
  • Working time: 4 hours
  • Charging time: 3 hours
  • Power input: 5V/2A USB-C
  • Screen size: 5 inch
  • Screen resolution: 800*480 px
  • Screen brightness: 500 cd/m2
  • Aspect ratio: 16:9
  • Language: English
  • Working temperature: 14℉ ~ 104℉ / -10℃ ~ 40℃

SwellPro Fisherman Max 4K Camera Specifications

Think of it as a GoPro for you drone. Every bit as sophisticated and with even more features, plus it flies. 😉

SwellPro Fisherman MAX FD2 4K camera
  • Waterproof rating: IP67
  • Stabilization: 1-axis (tilt)
  • Tilt range: -90° to 0°
  • Weight: 0.38 lbs / 176.5 g
  • Size: 3.1*2.7*2.7 inch / 79*69*70 mm
  • Image sensor: SONY IMX377
  • Shutter speed: 16 – 1/16000 s
  • Video resolution: 4K:30fps | 2.7K:60fps | 1080P:120/60/30fps | 720P: 240/120/60fps
  • Photo resolution: 4000*3000 (4:3), 3840*2160 (16:9)
  • Max video bitrate: 60 Mbps
  • Photo format: JPEG / DNG (RAW)
  • Video format: MP4 /MOV
  • Supported memory card: microSD card with a maximum capacity of 128GB, write speed ≥ 60 MB/s, recommend using Class 10 or above & UHS-1 rating
  • Working temperature: 14℉ ~ 104℉ / -10℃ – 40°C
  • Lens: F4.53mm f/2.65, FOV: 92.6°
  • ISO range: 100 – 3200
Urban Drones banner with logo

SwellPro Fisherman Max Heavy Lift Fishing Drone Pros and Cons


The following are some of the Pros and Cons of the new SwellPro Fisherman Max drone. Other than the price tag, which can be tough on your budget, there are very few cons. I would like to see them include an extra battery in the package so you can be fishing with one while the other one is charging.

SwellPro Fisherman MAX Pros
7.7 lb payload capacity
Controller with built in 5 in Screen
Auto Fish – Programmable Hands Free Flights
IP67 Seawater-proof to 1 meter for 30 min.
Maintain stability in wind up to 40 mph
1 Year Manufacturers Warranty
SwellPro Fisherman MAX Cons
price – not a cheap piece of equipment
only 1 battery included in basic package

SwellPro Fisherman Max FD2 vs The Competition


The SwellPro Fisherman Max FD2 has the payload capacity of the largest fishing drones on the market. Its main competition would be it is own sister models the Fisherman FD1, and the SplashDrone 3 and 4. Outside competition, for this size drone would be the Gannet Pro Plus Drone and SharkX drone from Rippton.

Both have similar payload capacities, and are good drones, but they don’t compare with all the features that SwellPro packs in the Fisherman MAX FD2. Gannet has had some supply chain issues from the COVID pandemic and it is aftermath and the SharkX doesn’t have the range of the SwellPro nor does it have a camera. The table below will highlight the differences between the SwellPro Fisherman Max and the competition.

FeatureSwellPro Fisherman MAXSwellPro Fisherman FD1SharkX DroneGannett Pro Plus
SwellPro Fisherman Max fd2 fishing droneSwellPro Fisherman FD1 fishing drone landing in the waterSharkX fishing drone - SharkX fishing drone review
Payload7.7 lbs – 3.5 kg4.4 lbs – 2 kg6.7 lbs – 3 kg7.7 lbs – 3.5kg
Battery Life30 min with no load30 min with no load24 minUp to 60 min
RemoteBuilt in ScreenBuilt in ScreenNo Screen Need Smart DeviceScreen for drone data only
ProgrammableYes – Auto Fish AppNoYes with AppNo
PriceExpensive But Most FeaturesGreat ValueGood for Heavy Lift DroneMost Expensive

Final Verdict: SwellPro Fisherman Max FD2 Heavy Lift Fishing Drone


The SwellPro Fisherman MAX is the drone many of us have been waiting for SwellPro to build. They already make the best waterproof dedicated fishing drones in the industry but the payload capacity was just a bit lacking for shark fisherman that use big heavy baits and gear.

SwellPro heard our pleas and will be releasing the all new Fisherman MAX May 1, 2023. Finally, a waterproof fishing drone with 7.7 lbs of payload capacity, 4k camera, Auto Fish hands free programmable, remote with build in view screen and able to fly in up to 40 mph winds. That, along with all the other awesome features included with SwellPro drones makes the Fisherman MAX the best pure fishing drone on the market.

As always, stay safe, enjoy the journey and please try to leave it cleaner than you found it. If you have any comments, questions, ideas or suggestions please leave them in the comment section below and I’ll get back to you asap. You can follow up on Facebook: Rex The Beach Angler, Instagram: thebeachangler7, Twitter: @AnglerBeach, and YouTube: Man Art Creations.
